The Hobbywing Fusion 8IGHT 1800KV FOC brushless system provides smooth low-speed control with considerably more power available for trail driving. The drivetrain combines a 2-speed gearbox, reverse, selectable RWD/FWD/4WD and independently controlled front and rear differential locks, giving the Bronco a particularly versatile drivetrain setup.
The scale chassis uses independent front suspension and a 4-link solid rear axle, while the CNC aluminium wheels, metal drivetrain components and oil-filled shocks give it a more premium setup than the brushed version.
It also features an extensive scale LED lighting system, detailed interior and dashboard, functional steering-wheel movement, and a quick-release officially licensed Bronco Raptor body.
| Specification |
Details |
| Scale |
1/8 |
| Model |
Ford Bronco Raptor |
| Power System |
Brushless FOC |
| Motor / ESC |
Hobbywing Fusion 8IGHT |
| Motor KV |
1800KV |
| Battery Compatibility |
2S–4S LiPo |
| Battery Connector |
XT60 |
| Transmission |
2-Speed planetary gearbox + Reverse |
| Drive System |
Selectable RWD / FWD / 4WD
|
| Differentials |
Remote independent front & rear differential locks |
| Steering Servo |
TH1230 30KG Coreless
|
| Radio System |
FlySky FS-G7P+ 10-Channel 2.4GHz |
| Gyro |
Yes |
| Front Suspension |
Independent double-wishbone |
| Rear Suspension |
4-link solid axle |
| Shocks |
Adjustable oil-filled metal shocks |
| Chassis |
1.5 mm steel C-channel frame |
| Driveshafts |
Heavy-duty metal driveshafts |
| Wheels |
2.2" CNC aluminium wheels |
| Tires |
KO2-style all-terrain, approx. 120 × 43 mm
|
| Overall Length |
625 mm |
| Overall Width |
282 mm |
| Overall Height |
255 mm |
| Wheelbase |
376 mm |
| Ground Clearance |
43 mm |
| Approach Angle |
48.5° |
| Breakover Angle |
36.5° |
| Departure Angle |
38° |
| Body |
Licensed Ford Bronco Raptor polycarbonate body |
| Body Mounting |
Quick-release |
| Configuration |
RTR – Ready to Run |
